ASUS Prime 650W Bronze

Model
- PRIME-650B-BLACK

Intel Form Factor
- ATX12V

PFC Type
- Active PFC

ATX Standard
- NA

80 PLUS Efficiency
- 80Plus Bronze

Protection Features
- OPP/OVP/UVP/SCP/OCP/OTP

Hazardous Materials
- ROHS

AC Input Range
- 100-240Vac

DC Output Voltage
+3.3V +5V +12V -12V +5Vsb

Maximum Load
- 20A 20A 54A 0.3A 2.5A

Combined Load
- 110W 110W 648W 3.6W 12.5W

Total Output
- 650W

Cable Connectors
MB 24/20-pin x 1
CPU 4+4-pin x 1
PCI-E 8-pin x 2
SATA x 5
PERIPHERAL x 3

Package Contents
Power Cord x 1
CPU cable x 1 (800mm)
PCI-E 1-to-2 x 1 (600mm)
SATA 1-to-2 cable x 1 (400+120mm)
SATA 1-to-3 cable x 1 (400+120+120mm)
Peripheral 1-to-3 cable x 1 (400+120+120mm)
User Manual x 1

Dimensions
- 150 x 150 x 86 mm

Weight
- Single PSU : 2.2KG
Product Weight (with packing) : 3.067KG

AURA SYNC
- No

MTBF
>120,000 hrs @ 25°C

0dB Fan Button
No, this product is without 0dB technology.
